Panasonic's AG-AC90 AVCCAM combines the high image quality, advanced functions and easy operation that professionals demand in a stylish, easy-to-handle design. The high-speed F1.5 lens extends from 29.8 mm (35 mm equivalent) wide-angle to 12x optical zoom. The AVCHD recorder section supports both PS mode, for Full-HD progressive image production, and pro-use PH mode. They realize the versatile shooting angles, image quality, and recording formats you need for news gathering and image production. Other professional operating features include triple manual rings (focus, zoom and iris), XLR microphone/audio inputs, and remote terminals to provide the system capabilities that professional applications require.
The Panasonic AG-AC90 AVCCAM Handheld Camcorder features 1/4.7"" 3MOS sensors, with 2.19MP each, to capture Full HD 1920x1080 resolution video. Variable frame rates record HD video at 60p, 60i, 30p, and 24p. The camera's fixed lens has a 12x zoom ratio, up to f/1.5 brightness, a 35mm equivalent of 29.8-357.6mm and manual control rings for focus, zoom and iris. In addition, Nano Surface Coating works to reduce ghosting and flare.
The AG-AC90 has two SD card slots for expanded memory or simultaneous recording to both cards for an instant back-up. A five-axis image stabilizer improves stabilization for handheld shooting, and 4x pixel shifting technology helps to create a sharper image. An Intelligent 25x digital zoom function makes automatic adjustments of edge, gradation and detail.
Professional AVCCAM HD recording modes include PS mode, which records 1080/60p at 28 Mbps. Additionally, PH mode averages 21-24 Mbps, and HA mode clocks in at approximately 17 Mbps. Finally, for extended recording times, HE mode uses approximately 6 Mbps. The AG-AC90 is compatible with Panasonic's ultra high-speed UHS-1 series of memory cards, as well as SDXC and SDHC cards.
In addition to the built-in microphone, two XLR audio inputs provide an interface for professional grade, external microphones. Audio Channel 1 and Channel 2 feature individual level controls and input selection.
|
Sensor Type |
MOS (x3, with backside illumination) |
|
Sensor Size |
1/4.7" |
|
Sensor Resolution |
2.19 MP (2,190,00 effective pixels) |
|
Minimum Illumination |
Approx. 3 lx (iA mode, auto slow shutter ON) |
|
Lens |
|
|
Focal Length |
2.84 - 34.1 mm |
|
35mm Equivalent Focal Length |
29.8 - 357.6 mm |
|
Zoom Ratio |
12x optical |
|
Aperture |
Max: f/1.5 |
|
Optical Image Stabilization |
5-Axis Hybrid OIS |
|
Lens Coating |
Nano Surface Coating |
|
Control Rings |
x3 (focus, zoom, iris) |
|
Filter Thread |
49 mm |
|
Image Stabilization |
Optical (hybrid optical image stabilizer, active mode) |
|
Recording Specifications |
|
|
Signal System |
NTSC (60 Hz) |
|
Video Format |
AVCHD version 2.0 compliant, AVCHD Progressive |
|
Compression |
Video: MPEG-4 AVC/H.264 |
|
Frame Rates |
HD 1080: 60p, 60i, 30p, 24p |
|
Recording Modes |
PS mode: approx. 28 Mbps (60p only) |
|
Shutter Speed |
60i/60p/30p: 1/30 to 1/2000 (auto slow shutter ON), 1/60 to 1/2000 (auto slow shutter OFF) |
|
Audio Channels |
CH1, CH2 |
|
Audio Format |
Dolby Digital |
|
Still Capture |
3 MP still photographs (can be captured during video recording) |
|
Interface |
|
|
Recording Media |
SD Card Slot (x2, compatible with UHS-1 and SDXC/SDHC/SD memory cards) |
|
Input/Outputs |
HDMI output (1080p/1080i/480p) |
|
General Specifications |
|
|
Displays |
Monitor: 3.5" LCD with 1,152 K dot resolution (rotates 270) Viewfinder: 0.24" LCOS color EVF with 263 K dot resolution |
|
Supply Voltage |
DC 12V (when the AC adaptor is used) |
|
Power Consumption |
12.9 W |
|
Operating Temperature |
32 ~ 104 F (0 ~ 40 C) |
|
Operating Humidity |
10 - 80% (no condensation) |
|
Dimensions |
6.31 x 7.69 x 13.06" (160 x 195 x 350 mm) |
- Brand New Factory Fresh Import Model
